2. If F2 is selected, the following menu will appear:
F2-DATABASE
F3-PROGRAM
Based on which selection from this menu is made the following operations will occur:
F2- DATABASE:
This copies the entire database, all B,L,C,H,A, and F datapoint values, in the con-
troller to the storage cartridge. Transfer takes approximately 12 seconds.
F3- PROGRAM:
This copies all the user written F-TRAN programs and the F-CIM programs in the
controller to the storage cartridge. Transfer takes approximately 20 seconds.
When the transfer begins a message indicating that the transfer has started will be displayed.
When the transfer is completed a message indicating completion will be displayed. If for some rea-
son the transfer failed, an error message will be displayed in place of the completed message. If
an error occurs resolve the problem and reinitiate the transfer. No transfer error should be ignored
since a partial transfer may have left the instrument cartridge in an indeterminate condition. Upon
completion or error the HHC is again in the command entry mode.
3.3.1.7 SAMPLE HAND HELD CONFIGURER OPERATION
The following table provides a sample of typical Hand Held Configurer Display (
D ), Put (P ), and
Memory Transfer (
T ) commands.
Key Entries
Displayed Data
Result
D B101
D B101 XXX
Displays contents of B101.
D N
D B102 XXX
Displays contents of Next (N)
datapoint, B102.
D
D B102 XXX
B102 contents still displayed. It
updates the display value of the
current datapoint.
P C256
P C256 XXX 200
Alters contents of C256 to 200
P
P C256 XXX 150
Alters contents of C256 to 150.
It alters the value of the current
datapoint.
P N 200
P C257 XXX 200
Alters contents of C257 to 200.
It alters the value of the Next (N)
datapoint.
T
MEMORY TRANSFER
F1 - TO CONTROLLER
F2 - FROM CONTROLLER
✦
✦
✦
TRANSFER FINISHED
Displays memory transfer query
t o e i t h e r s e n d c a l i b r a t i o n
c o n s t a n t s , d a t a b a s e , o r
programs to the instrument; or
receive database or programs
from the instrument for storage
into the memory module.
Note:
XXX = Displayed characters from the addressed datapoint.
