2.5 CORD SETS (OPTIONAL)
2.5.1 GENERAL
The 53MC5000 Cord Set receptacle and cables are an alternate method of interconnecting the
Controller to a remotely mounted interconnection terminal block(ITB). The standard instruments
have screw type terminals directly mounted on the rear terminal board. In the cord set version the
screw type terminals and associated circuit board are removed and in its place a circuit board that
terminates in receptacles is furnished.
2.5.2 INSTALLATION
The Cord Set Case is assembled as part of the instrument before leaving the factory. Carefully re-
move the instrument assembly from its packing case. After the instrument has been mounted in the
panel, install the cable or cables. The latches on the plug must engage the receptacle keepers.
2.5.3 INTERCONNECTIONS
The accessory cable and standard lengths are as follows:
1. Signal Cable, standard (20 conductor) - used for control signals, 4AI, 2AO, 2DOs, 2DIs;
standard length 5 feet .
2. Data Link Cable for unit to unit interconnect (6 conductor) - used for connection of one
controller to another; standard length 30 inches with a 6 conductor connector on each end.
3. Refer to Figures 2-7 through 2-9 of this manual and Figures 2-12 through 2-14 of Instruc-
tion Bulletin 53MC5000.
