3.4.6 CONTROLLER MODULE
Up to four CON modules are present in the controller. Compare the model number on the controller
with the model number breakdown in Section 1.2 to determine the number of loops accessible.
These parameters control the action of the control algorithms and the content of the control loop
displays.
MODULAR CONTROLLER QUICK START
3-34
