The side compartment of MAGPIX contains the majority of user-maintainable components.
The access door to this compartment must remain latched during operation of the instrument.
Opening the access door requires a special tool provided with the MAGPIX system.
FIGURE 51. Side Access Door Latch
To open the latch:
1. Turn off and unplug MAGPIX.
2. Insert the latch tool into the slot of the latch and turn it clockwise.
3. Slide the door to the right.
Daily Procedures
Most of the daily maintenance tasks for MAGPIX can be performed using available software
commands.
For details about performing these commands, refer to the xPONENT for MAGPIX Software
User Manual or online help.
