Preparing the magpix for first use – Luminex MAGPIX Hardware and Installation Manual User Manual
Page 31
3. Connect the USB cable to the PC and to the connector labeled P1 on the back of
MAGPIX. Use the top right USB port on the back of the PC.
FIGURE 16.
Power Cord and USB Cable Connected
4. Connect the barcode scanner (if ordered) to the computer, to a USB port on either the
front or back.
FIGURE 17.
All Components Connected
Preparing the MAGPIX for First Use
MAGPIX
®
18
