Unpacking and Assembling the PC
Begin the installation process with the PC. The computer and monitor are in the boxes at the
end of the overpack; the monitor stand is in a box underneath the accessory tray.
The computer and monitor boxes include all the necessary cords and peripheral devices as
well as complete installation instructions. Follow those instructions to set up the PC.
To set up the PC:
1. Remove the three boxes containing PC components from the overpack.
2. Assemble the components using PC Installation Instructions foldout (PN
89-30000-00-263) included in the Installation Instructions packet or the instructions
provided by the PC vendor.
FIGURE 10. The Assembled PC
Unpacking and Assembling MAGPIX
To install the MAGPIX instrument:
