Models 5800-S
Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
5
Section 1 Introduction
1.1 Purpose
This instruction manual is intended to provide the user with all the information
necessary to install, operate and maintain the Brooks Smart series Mass Flow
meters 5860S, 5861S, 5863S and controllers 5850S, 5851S, 5853S.
1.2 How to use this Manual
It is recommended to read this manual before installing, operating or repairing
these Mass Flow Instruments. This manual is organised into nine sections:
Section 1. Introduction
Section 2. Installation
Section 3. Operation
Section 4. Maintenance
Section 5. Specification
Appendices A - E
This instruction manual is intended to provide the user with all the information
necessary to install, operate and maintain the Brooks Smart Mass Flow Meters
and Controllers.
This series of microprocessor-based field instruments is designed to meet the
rigorous demands of various industries/applications. The use of digital
technology ensures that the Brooks Smart series provides maximum accuracy
and signal integrity. In addition it allows easy interfacing to any peripheral
equipment either through analogue or digital communication.
This manual covers Smart Mass Flow Meter models: 5860S, 5861S, 5863S and
5864S and Smart Mass Flow Controller models: 5850S, 5851S and 5853S.
Digital communication
The presence of a computer icon to the left of the text (as shown here) denotes
that the accompanying text refers to digital communication.
Smart Control
Digital communication (either via RS-232 or RS-485) allows to connect our
Brooks model 0160 Smart Control. This interface program can be used to
operate and (re)configure Smart Mass Flow Products (calibration parameters are
not accessible).
Smart DDE
If you require bi-directional links between your Windows-based applications
software and Brooks Smart Mass Flow Products,our model 0162 Smart DDE
(a powerful, user-friendly Dynamic Data Exchange software program) offers all
the features you need.
