Models 5800-S
Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
45
M ECHANICAL CONNECTIONS
1A
WITHOUT A DA PTORS (9/16"-18" UNF)
(ONLY FOR 5850/60/51/61/53/63)
1B
1/4"
TUBE COMPRESSION FITTINGS
(ONLY FOR 5850/60/51/61)
1C
1/8"
TUBE COMPRESSION FITTINGS
(ONLY FOR 5850/60/51/61)
1D
3/8"
TUBE COMPRESSION FITTINGS
(ONLY FOR 5851/61)
1E
1/4" V CR
(ONLY
FOR
5850/60/51/61)
1F
1/4" V CO
(ONLY
FOR
5850/60/51/61)
1G
1/4" NPT
(ONLY
FOR
5850/60/51/61)
1H
6mm
TUBE COMPRESSION FITTINGS
(ONLY FOR 5850/60/51/61)
1J
10mm
TUBE COMPRESSION FITTINGS
(ONLY FOR 5850/60/51/61)
1K
1/4"
BSP (F)
(ONLY FOR 5850/60/51/61)
1Y
½ "
BSP (F)
(ONLY FOR 5853/63)
1Z
1"
BSP (F)
(ONLY FOR 5853/63)
2A
1 1/16" - 12SA E/MS
(ONLY FOR 5853/63)
2B
½ "
TUBE COMPRESSION FITTINGS
(ONLY FOR 5850/60/51/61/53/63)
2C
3/4"
TUBE COMPRESSION FITTINGS
(ONLY FOR 5853/63)
2D
1"
TUBE COMPRESSION FITTINGS
(ONLY FOR 5853/63)
2E
½ " NPT(F)
(ONLY
FOR
5853/63)
2F
1"
NPT(F)
(ONLY FOR 5853/63)
2G
1½ " NPT(F) (SEE OPTION "E")
(ONLY FOR 5853/63/64)
2H
½ "
V CO (200 ln/min. max .)
(ONLY FOR 5850/60/51/61/53/63)
2J
3/4" V CO
(ONLY FOR 5853/63)
2K
½ "
V CR (200 ln/min. max .)
(ONLY FOR 5850/60/51/61/53/63)
2L
DIN
DN15PN40
(ONLY FOR 5853/63)
2M
DIN
DN25PN40
(ONLY FOR 5853/63)
2N
DIN
DN40PN40
(ONLY FOR 5853/63)
2O
DIN
DN50PN40
(ONLY FOR 5853/63)
2P
A NSI ½ " 150 LBS
(ONLY FOR 5853/63)
2R
A NSI ½ " 300 LBS
(ONLY FOR 5853/63)
2S
A NSI 1"
150 LBS
(ONLY FOR 5853/63)
2T
A NSI 1"
300 LBS
(ONLY FOR 5853/63)
2U
A NSI 1½ " 150 LBS
(ONLY FOR 5853/63)
2V
A NSI 1½ " 300 LBS
(ONLY FOR 5853/63)
2W
A NSI 2"
150 LBS
(ONLY FOR 5853/63)
2X
A NSI 2"
300 LBS
(ONLY FOR 5853/63)
2Y
1"
V CO
(ONLY FOR 5853/63)
2Z
3/4"
V CR
(ONLY FOR 5853/63)
9Z
SPECIFY
O-RING/V ALV E SEAT M ATERIAL
A
V ITON
B
BUNA (NOT FOR 5853 s ee Options 3, " I ")
C
PTFE/KA LREZ (KA LREZ SENSOR O-RINGS & V A LV E SEA T) (NOT FOR 5853/63)
D
KA LREZ (NOT FOR 5853/63 see Options 3, " I ")
E
PTFE O-RINGS / EPDM V A LV E SEA T (Tef lon Diaphragm f or 5853)
M
KA LREZ O-RINGS / META L V A LV E SEA T (NOT FOR 5853/63)
Z
SPECIFY
Appendix E
