47
ENHANCEM ENTS
A STA NDA RD RESPONSE:< 1 SEC (5850/51) < 3 SEC (5853) [1].
B FA ST RESPONSE (SPECIFY V A LUES .... SEC.) [1]
C LINEA R RA MP (SPECIFY V A LUES ....% /SEC.) [1]
D FLOW OUTPUT DA MPING (SPECIFY V A LUES .... SEC.) [1]
CALIBRATION
0 UNCA LIBRA TED
1 STA NDA RD CA LIBRA TION INCLUDED
2 STORA GE OF MULTIPLE CA L. CURV ES; A DD PER A V A ILA BLE
CA LIBRA TION GA S
9 SPECIFY
POWER SUPPLY INPUT
A ± 15 V dc
B + 24 V dc = (Standard s elec tion)
C + 15 V dc only
Z SPECIFY
AREA CLASSIFICATION
1 SA FE A REA
2 CERTIFIED FOR USE IN ZONE 2
9 SPECIFY
5850S/BC 1H A 1 A B3 C A 1 B 1 = TYPICAL M ODEL NUM BER
BROOKS SMART MASS FLOW PRODUCTS
SMART MASS FLOW METERS / CONTROLLERS
NOTES:
1.
ENHANCEMENTS
PLEASE FILL IN THE REQUESTED SPECIFICATIONS WHEN YOU HAVE DESCRIBED THE ENHANCEMENTS.
Standard response time of the flow output signal: Model 5850/51 and 5860/60, standard 1 sec. or on request better
than 0.2 sec. Model 5853/63, standard 3 sec. or on request better than 1 sec. Model 5864, 3 sec.
Standard settling time for controllers: Model 5850/51, standard 1 sec. or on request better than 0.2 sec.
Model 5853, standard 3 sec. or on request better than 1 sec. (to within 2%full scale of final value)
2.
AREA SAFETY CLASSIFICATION
A "SPECIAL" CABLE CONNECTOR IS REQUIRED FOR ZONE 2 CERTIFICATION REQUIREMENTS.
THIS WILL BE SUPPLIED WHEN YOU HAVE SELECTED THE INTERCONNECTING CABLE. IF THE CUSTOMER
MAKES HIS OWN CABLE SET; YOU ALWAYS HAVE TO SELECT POSITION B - "MATING CONNECTOR ONLY".
Appendix E
