Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
Models 5800-S
10
2.3 Recommended Storage Practice
If equipment supplied by Brooks Instrument is to be placed in intermediate or
long-term storage, it is recommended that it be:
a. Stored within the original shipping container.
b. Stored in a sheltered area, under the following conditions:
1) Optimum ambient temperature 21°C (70 °F), maximum 32 °C (90 °F),
minimum 7 °C (45 °F),.
2) Optimum relative humidity 45% (maximum 60%/minimum 25%).
c. Subjected to a visual inspection upon removal from storage, to verify that the
condition of the equipment is ‘as received’. If the equipment has been in
storage for more than ten months or if it has not been stored under the
recommended conditions, all pressure containing seals should be replaced.
In addition, the device should be subjected to a pneumatic pressure test in
accordance with the applicable vessel codes.
2.4 Return Shipment
Prior to returning any instrument to the factory, contact your nearest Brooks
location for a Return Materials Authorization Number (RMA#). This can be
obtained from one of the following locations:
Brooks Instrument
407 W. Vine Street
P.O. Box 903
Hatfield, PA 19440 USA
Toll Free (888) 554-FLOW (3569)
Tel (215) 362-3700
Fax (215) 362-3745
Email: [email protected]
http://www.brooksinstrument.com
Brooks Instrument Brooks Instrument
Neonstraat 3 1-4-4 Kitasuna Koto-Ku
6718 WX Ede, Netherlands Tokyo, 136-0073 Japan
P.O. Box 428 Tel 011-81-3-5633-7100
6710 BK Ede, Netherlands Fax 011-81-3-5633-7101
Tel 31-318-549-300 Email: [email protected]
Fax 31-318-549-309
E-mail: [email protected]
Any instrument returned to Brooks requires completion of Form RPR003-1,
Brooks Instrument Decontamination Statement, as well as, a Material Safety
Data Sheet (MSDS) for the fluid(s) used in the instrument. This is required
before any Brooks Personnel can begin processing. Copies of the form can be
obtained from any Brooks Instrument location listed above.
2.5 Gas Connections
All models are fitted with the following inlet and outlet connectors as standard:
NPT(F), tube compression fittings, VCR, VCO, DIN or ANSI flanges. Prior to
installation, make certain that all piping is clean and free of obstruction. Install
the piping in a manner that permits easy access to the instrument, should it
need to be removed for cleaning or test-bench troubleshooting.
Section 2: Installation
