Brooks Instrument 5800S Series - Manual (Page 48)

Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
Models 5800-S
48
3.
OPTIONS
A) HIGH PRESSURE RATING 300 BAR FOR MODEL 5861S
B) FOR GASES WHICH CLOG AND CONTAMINATE THE MFC EASILY, AN ANTI-CLOG LAMINAR FLOW ELEMENT
MUST BE ORDERED. FOR FLOW RANGES UP TO 3460 mln/min. N2, ADD:
C) 0 - 10 Vdc I/O CONFIGURATION (NO FURTHER I/O OPTIONS ARE POSSIBLE WITH THIS SELECTION)
D) 0 - 5 Vdc Input / 0 - 10 Vdc output (0550E replacement configuration)
E) DIN/ANSI (PN40/150 LBS PRESSURE RATING) FLANGED CONNECTION FOR THE 1,5" AND 2" 5864S
F) ENHANCED ACCURACY SPECIFICATIONS: 0.5% OF RATE PLUS 0.1% F.S. (Flow range 50 mln/min to 100 ln/min)
G) INTERCONNECTION CABLE, ADD PER METER:
H) INTERCONNECTION CABLE FOR RS-485 MULTI DROP CONFIGURATION,
BASIS PRICE FOR THE FIRST DEVICE (3 METER CABLE LENGTH)
ADD PER METER:
PRICE ADDER FOR AN ADDITIONAL DEVICE (1 MTR CABLE LENGTH):
I) O-RING / VALVE MATERIAL
Selection B can only be delivered for a 5853 model in combination with a Teflon Diaphragm
Selection D can be delivered only in combination of a Teflon Diaphragm for Model 5853 price adder
Selection D for Model 5863 price adder
Appendix E
