Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
Models 5800-S
46
V ALV E TYPE
0 METER ONLY (NO V A LV E)
1 NORMA LLY CLOSED (5850/51 SERIES)
2 NORMA LLY CLOSED (PRESS.DIFF. >2BA R. 5853 SERIES)
3 NORMA LLY CLOSED (PRESS.DIFF. <2BA R. 5853 SERIES)
4 NORMA LLY OPENED (5850 ONLY )
5 NORMA LLY CLOSED, 5850 SERIES, 300 BA R
9 SPECIFY
ELECTRICAL INPUT/OUTPUT
INPUT OUTPUT
A 0-5V dc 0-5 V dc & 0-20mA (INCL. RS 232, 9600 BDS)
B 4-20mA 4-20 mA & 1-5V dc (INCL. RS 232, 9600 BDS)
C 0-20 mA 0-20mA & 0-5V dc (INCL. RS 232, 9600 BDS)
D 1-5V dc 1-5 V dc & 4-20mA (INCL. RS 232, 9600 BDS)
E DIG. COMM. DIG. COMM. + 0 - 5 V dc
F DIG. COMM. DIG. COMM. + 4 - 20 mA
G DIG. COMM. DIG. COMM. + 0 - 20 mA
H DIG. COMM. DIG. COMM. + 1 - 5 V dc
I DIG. COMM. DIGITA L COMMUNICA TION (ONLY )
Z SPECIFY
COM M UNICATION / BAUDRATE
A 0 NONE (Communic ation w ill be pos s ible v ia RS/232 and 9600 baud)
B* RS232
C* RS485
D 0 PROFIBUS-DP (PNO CERTIFIED, 831-A -023 and 541-C-068-A A G)
E 0 PROFIBUS-DP (not CERTIFIED, 831-A -021 and 541-C-062-A A G)
F* CA RDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICA TION)
G* CA RDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICA TION) RS-232
H* CA RDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICA TION) RS-485
*1 38400 Baud
*2 19200
*3 9600
*4 7200
*5 4800
*6 3600
*7 2400 * BOTH HA V E TO BE SPECIFIED
*8 1200
INTERCONNECTION CABLE
A NO CA BLE
B MA TING CONNECTOR ONLY
C 3m ROUND CA BLE
D 6m ROUND CA BLE
E 3m ROUND CA BLE INCLUDING COMMUNICA TION CA BLE
F 6m ROUND CA BLE INCLUDING COMMUNICA TION CA BLE
Z SPECIFY
Appendix E
