Models 5800-S
Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
15
Table 2-2: Dipswitch settings
Switch
#1
Switch
#2
Switch
#3
Switch #4
RS-232
Off
RS-485
On
1200
Off
Off
Off
2400
On
Off
Off
3600
Off
On
Off
4800
On
On
Off
7200
Off
Off
On
9600
On
Off
On
19200
Off
On
On
38400
On
On
On
Baud rate
selection
Physical
layer
selection
Dipswitch block SW1
Since Brooks Smart Mass Flow devices are capable of communication
immediately after start-up, you should set the correct baud rates prior to power
up. Any changes to the baud rate settings or the physical layer selection made
during operation will take effect immediately. The communication I/O drivers are
directly connected to the D-connector on top of the device.
The RS-232 is essentially a point-to-point connection, i.e. one host-computer
and one Smart Mass Flow device. Most IBM-compatible PCs are equipped with
one or more RS-232 ports (COM ports) as standard. The RS 232 usage and
definitians are very diverse. On the MF Smart Mass Flow devia the TxD signal is
the output signal of the devia and the RxD the input signal.The communication
terminals can be directly connected to a serial COM-port of any PC. The other
part of the terminals can be connected to Brooks model 0152/0154
Microprocessor-based Read-out and Control Electronics. This model provides
the power supply for Smart Mass Flow devices, as well as providing local
read-out and displaying the analogue output signals. Figure 2-3 shows the
interconnection diagram of the RS-232 configuration. The pin assignment on an
IBM Compatible PC. This is standard for RS-232.
Section 2: Installation
