69

AC Voltage

Resolution, Full Scale reading and Accuracy

Range

Resolution

Full Scale Reading

500.00 mV

5.0000 V

50.000 V

500.00 V

750.0 V

10 μV
100 μV
1 mV

10 mV

100 mV

510.00

5.1000

51.000

510.00

757.5

(1)

(1)

1% over-range (757.50 V) is readable at 750 V range

ACCURACY: ± (% of reading + % of range), 23 °C ± 5 °C

Rate

Range

Accuracy(1 year)

(1)

23 °C ± 5 °C

20-50 Hz

50-20 kHz

20-50 kHz

50-100 kHz

Slow

500.00 mV

5.0000 V

50.000 V

500.00 V

750.0 V

1.0%+0.08%

1.0%+0.08%

1.0%+0.08%

------

------

0.5%+0.06%

0.35%+0.02%

0.35%+0.02%

0.5%+0.03%

0.5%+0.03%

1.5%+0.1%

1%+0.04%

1%+0.04%

1%+0.04%

1%+0.04%

(2)

3.0%+0.3%

3.0%+0.1%

3.0%+0.1%

3.0%+0.1%

3.0%+0.1%

(2)

(1)

Specifications are for sine wave inputs >5% of range.

(2)

Limit at 40 kHz

or ≤3×10

7

Volt-Hz for 750 V range

Measurement method: True RMS measurement

Maximum Crest factor: 3.0 at full scale

Maximum input voltage: 750 Vrms
≤3×10

7

Volt-Hz for all ranges

Input impedance: 1

MΩ ± 2% in parallel with capacitance <100 pF

Maximum DCV: 500 V for all AC ranges
