To set the reference voltage, perform the following steps:

1. Press

+

for dB math operation and the present reference value is displayed:

R.F:+0.00000

2. Use

and

keys to choose a numerical place and use

and

keys to

increment or decrement the digits. Enter a value and units prefix.

3. Press

(ENTER) to confirm the reference voltage, the message

SAVED” will be displayed for

a moment. Then the meter will return back to the measurement status.

4. The display will now show result of the dB calculation.

If you want to change the parameter values when dB function is in effect, you can do the following:

1. Press

to enter the menu on the menu level,

A: MATH MEU” will be displayed.

2. Press

to move down to the command level within the MATH MEU,

4: dB REF “will be

displayed.

3. Press

to enter the parameter level, and the present reference value will be displayed:

R.F: +1.00000 .

4. Use

and

keys to choose a numerical place and use

and

keys to

increment or decrement the digits. Enter a value and units prefix.

5. Press

(ENTER) to confirm the reference value, the message

SAVED” will be displayed for a

moment, and the meter will return to the command level. Press

to cancel the reference value

input, and the meter will return back to the command level without changing the reference value.

6. Press

key to exit the menu and return to the dB math operation status.

Note:

The dB calculation takes the absolute value of the ratio V

IN

/V

REF

. The largest negative

value of dB is -160 dB. This will accommodate a ratio of V

IN

= 1 µV, V

REF

= 1000 V.

3.9.3 dBm Calculation

dBm is defined as decibels above or below a 1 mW reference. With user-programmable reference

impedance, the meter reads 0 dBm when the voltage needed to dissipate 1 mW through the reference

impedance is applied. The relationship between dBm, reference impedance, and the voltage is defined

by the following equation:

mW

Z

V

dBm

REF

IN

1

)

(

log

10

2

Where:

IV

V

is the DC or AC input signal.

REF

Z

is the specified reference impedance.

If a relative value is in effect when dBm is selected, the value is converted to dBm then REL is applied to

dBm. If REL is applied after dBm has been selected, dBm has REL applied to it.
