39

 1200
 600

Note:

Factory default baud rate is 9600.

Before you choose a baud rate, make sure the programming terminal on a computer that will be used to

connect to the instrument supports the baud rate you selected. Both the digital multimeter and the

computer must be configured for the same baud rate.

Perform the following steps to select a baud rate

1. Press

to enter the menu on the menu level,

A: MATH MEU” will be displayed.

2. Use

or

key to move across to the SYS MEU on the menu level,

C: SYS MEU” will

be displayed.

3. Press

to move down to the command level within the SYS MEU,

1: BEEP STR” will be

displayed.

4. Use

or

key to move across to the baud rate command,

2: BAUD RAT” will be

displayed.

5. Press

to move down a level to set the baud rate.

6. Use

or

key to select a baud rate.

7. Press

(ENTER) to confirm the selection. The message

SAVED” will be displayed to show

that the change is now in effect. The multimeter will exit the parameter level and move up a level to

the command level.

8. Press

key to exit from the menu and return to the measurement status.

4.5.3 Selecting the Terminal Character

The instrument has two kinds of terminal characters: (Line Feed) and (Carriage Return).

Perform the following steps to select the terminal characters:

1. Press

to enter the menu on the menu level,

A: MATH MEU” will be displayed.

2. Use

or

key to move across to the SYS MENU on the menu level,

C: SYS MEU

will be displayed.

3. Press

to move down to the command level within the SYS MEU,

1: BEEP STA” will be

displayed.

4. Use

or

key to move across to the terminal character command,

3: TX TERM” will

be displayed.

5. Press

to move down a level to set the terminal character.

6. Use

or

key to select a terminal character.
