65
Chapter 7 Specifications
A-1 Introduction
Chapter 7 describes the complete specifications of the multimeter.
A-2 Technical Specifications
Specifications are based on the following conditions:
 One year calibration cycle.
 Operating temperature at 18 °C to 28 °C
 Accuracy is expressed as: ± (% of reading + % of range) after 30 minutes warm-up.
 Temperature Coefficient: add ± [0.1% × (the applicable accuracy)/°C] for 0 °C to 18 °C and
28 °C to 40 °C
 Relative Humidity: Up to 80% RH for 0 °C to 28 °C (75% RH for 10 M Ω and above ranges
for resistance measurement). Up to 70% RH for 28 °C to 40 °C
Displayed Readings and Reading rates
Reading rates on front panel (approximate reading/sec)
Measurement Function Slow Med Fast
DCV 5 10 25
DCA 5 10 25
ACV 5 10 25
ACA 5 10 25
Ω (Ranges below 2M ) 5 10 25
Ω (20M range and above)
1.3 2.6 5.6
Freq/ Period 1 2 3.9
Using dual display 0.9 0.9 0.8
True RMS DC+AC 1.2 1.4 1.5
Diode ———— 10 ————
Continuity ———— ———— 25
