60

:ACQuire

Command syntax:

:RESistance:REFerence:ACQuire

Acquire reference for

Ω

Description:

When one of these commands is sent, the measurement input signal is acquired and established as

the reference value. This command is typically used to zero the display. For example, if the

instrument is displaying a 0.1

Ω offset, sending this command and enabling reference zeroes the

display.

This command is functional only if the instrument is on the specified measurement function.

Sending this command while in any other function causes an error. Also, if the latest reading caused

an overflow condition or a reading has not been triggered, an error occurs when this command is

sent.

6.3.6 FREQuency and PERiod subsystem

The commands in this subsystem are used to configure and control frequency as well as period

measurement function and are summarized in Table 6-6.

Table 6-6

FREQency and PERiod Subsystem Commands Summary

Command

Function Description

Default

:FREQuency

:THReshold

:VOLTage

:RANGe

:RANGe?

:REFerence

:STATe

:STATe?

:ACQuire

:REFerence?

Path to configure frequency

Path to select the threshold voltage range:

Select threshold range (0 to 750).

Query threshold range

Specify reference (0 to 1.0e6)

Enable or disable reference

Query state of reference

Use input signal as reference

Query reference value

20

0

OFF

:PERiod

:THReshold

:VOLTage

:RANGe

:RANGe?

:REFerence

:STATe

:STATe?

:ACQuire

:REFerence?

Path to configure period

Path to select the threshold voltage range:

Select threshold range (0 to 750).

Query threshold range

Specify reference

Enable or disable reference

Query state of reference

Use input signal as reference

Query reference value

20

0

OFF
