57

6.3.5 RESistance subsystem

The commands in this subsystem are used to configure and control resistance measurement function

and are summarized in Table 6-5.

Table 6-5

RESistance Subsystem Commands Summary

Command

Function Description

Default

:RESistance

:NPLCycles

:NPLCycles?

:RANGe

[:UPPer]

[:UPPer]?

:AUTO

:AUTO?

:REFerence

:STATe

:STATe?

:ACQuire

:REFerence?

Path to configure resistance

Set integration rate (*power line cycles: 0.1, 1, 10)

Query line cycle integration rate

Path to configure measurement range

Select range (0 to 20e6)

Query range

Enable or disable auto range

Query auto range

Specify reference (0 to 20e6)

Enable or disable reference

Query state of reference

Use input signal as reference

Query reference value

1

20e6

ON

0

OFF

*Fast = 0.1, Medium = 1, Slow = 10


Speed Commands

: NPLCycles

Command System:

:RESistance:NPLCycles

Set NPLC for

Ω

Command Parameter:

= 0.1, 1, 10

Set power line cycles per integration

DEFault

1

MINimum

10

MAXimum 0.1

Query:

:NPLCycles?

Query programmed NPLC value

Description:

The integration period (measurement speed) for the basic measurement functions (except

Frequency and Period) is set using the :NPLCycles command. NPLC (Number of Power Line

Cycles) expresses the integration period by basing it on the power line frequency. For example, for a

PLC of 1, the integration period in seconds would be 1/60 (for 60Hz line power) which is 16.67 ms.
