11

HI/IN/LO Indicates the limit testing results

RMT

Multimeter is in remote control mode

AUTO

Auto ranging enabled

Max/Min MAX / MIN operation is enabled

ERR

Hardware or remote control error detected

SHIFT

Accessing shifted keys

2.3 Front Panel Menu Reference

A: MATH MENU

1: HI LIMIT

→ 2: LO LIMIT → 3: PERC REF → 4: dB REF→ 5: dBm REF

1. HI LIMIT

Set the high limit for limit testing.

2. LO LIMIT

Set the low limit for limit testing.

3. PERC REF

Set the reference value for PERCENT function

4. dB REF

Set the dB reference voltage value.

5. dBm REF

Set the dBm reference impedance value.

B: TRIGGER MENU

1: TRIG MOD

1. TRIG MOD

Select IMMediate, Manual or Bus trigger source mode.

C: SYSTEM MENU

1: BEEP STA

→ 2: BAUD RAT → 3: TX TERM → 4: RETURN → 5: KEY SONG → 6: REVISION

→ 7: ZERO CAL
1. BEEP STA

Enable or disable the beeper function

2. BAUD RAT

Select the baud rate for USB (virtual COM) or RS232 (Model 5491B only)

operation.

3. TX TERM Set the terminal character for USB (virtual COM) or RS232 (Model 5491B

only) operation, which identifies the end of a command string

4. RETURN

Sets whether to enable Echo of the “sent” SCPI commands in return string.
(i.e. if ON, sending *IDN? will return with *IDN? and model information on

two separate lines).

5. KEY SONG

Enable or disable the key sound when you press a key.

6. REVISION

Shows the model number and firmware version of the instrument.

7. ZERO CAL

Reserved for zeroing calibration of resistance measurement ranges.
