35

The RATE parameters are explained as follows:

Fast

FAST sets speed to 25 readings per second. Use FAST, if speed is of primary importance, however it is

at the expense of increased reading noise and fewer usable digits (resolution).

Medium

Medium sets speed to 10 readings per second. Use Medium to achieve a balance between noise

performance and speed.

Slow

Slow sets speed to 5 readings per second.

SLOW provides better noise performance and resolution at

the expense of speed.

Note:

The integration time can be set for any measurement function except frequency, period,

continuity (fixed at FAST rate) and diode test (fixed at Medium rate). For frequency and

period,

this value is little excess a gate time.

4.2 Trigger Operations

The multimeter’s triggering system allows you to generate triggers either manually, automatically or
externally, and take multiple readings per trigger. The following paragraphs discuss front panel triggering,

and the reading hold feature.

4.2.1 Trigger procedure

Wait for Trigger

The control source holds up operation until the programmable event occurs and is detected. See

description below for trigger sources:

 Immediate

With this trigger source, event detection is immediately satisfied allowing operation to continue.

 External

Event detection is satisfied for both kinds of triggers as below:

1. A bus trigger (*TRG) command is received.

2. The front panel

key is pressed (The multimeter must be taken out of remote

before it will respond to

key).

Take steps below for trigger settings:

1. Press

to enter the menu on the menu level.

A: MATH MEU” will be displayed.

2. Use

or

key to move across to the TRIG MEU on the menu level.

B: TRIG MEU

will be displayed.

3. Press

to move down to the command level within the TRIG MEU.

Trig

Trig
