VN-MATRIX User Guide Section 7: Technical Data
I458GB issue 6 Page 99
VN-MATRIX Hardware
Mechanical Data
Overall Dimensions: Width: 215mm (8.47 inches)
Depth: 308mm (12.17 inches) [including rear sockets]
Height: 44mm (1.74 inches) [excluding feet]
53mm (2.09 inches) [including feet]
Average Weight: 1.4 kg (3.1 lbs)
Operating Conditions
Ambient Temperature: 5°C to 35°C (41°F to 95°F).
Ambient Humidity: 85% maximum (non-condensing).
Location: Free-standing or 19” Rack-mounting (using approved kit).
Cooling Method: Internal fan (temperature controlled speed).
Power Supply
VN-MATRIX
Supply Voltage: 12V DC Regulated (via Mains Adapter)
Supply Current: 6A max.
MAINS ADAPTER
Supply Voltage: 100 – 240V AC nominal.
Supply Frequency: 50 – 60 Hz nominal.
Supply Current: 0.45A maximum.
Supply Inlet Connector: IEC320 (C14).
Supply Mating Connector: IEC320 (C13); suitable 2m (6ft) mains cord supplied.
