VN-MATRIX User Guide

Section 2: Installation & Basic Setup Procedures

I458GB issue 6

Page 31

Setup and Connection Procedure


Setting up and connecting a VN-MATRIX system is best undertaken in three stages. Briefly these are:

ƒ

Stage 1: Network Communications Setup

Configure the network settings for each device using a PC/laptop and serial data link,
ensuring that one device is configured as a controller. (See pages 32 to 34).

ƒ

Stage 2: Connection

Connect each device to the network and connect its associated source or display equipment.
(See pages 35 to 40).

ƒ

Stage 3: System Configuration

Using a PC/laptop connected to the same network to access the Web Interface (served by the
controller) configure each device to be an encoder (source) or decoder (display).
(See Section 3, page 41 onwards).


CAUTION: Do not proceed with connecting or configuring the VN-MATRIX for an existing network
until you are certain you know what you are doing – incorrect connection or configuration may cause
disruption to other network users.
