Section 3: System Configuration

VN-MATRIX User Guide

Page 50

I458GB issue 6

Device Mode


A VN-MATRIX encoder can be configured in three modes:

ƒ

enable allows the source to be streamed,

ƒ

disable prevents a source from being streamed,

ƒ

standby prevents a source from being streamed.

For normal operation, enable must be selected.

Audio Status


Where a valid digital audio signal is connected to the DIGITAL AUDIO IN connector, the type of signal
will appear in the Audio Status field on the Configure (audioPort) page.

VN-MATRIX supports the auto-detection of 44100 Hz and 48000 Hz digital audio sources.

Advanced Setup Options


The encoder set up procedure on the preceding pages will achieve a basic level of operation which
will be adequate for most normal applications.

The following advanced setup options are possible and these are detailed in Section 4:

Fine-tuning of input parameters

see page 65

Creation of custom input modes

see page 66

Changing video compression

see page 69

Managing bandwidth usage

see page 72

Changing audio compression

see page 73
