Section 3: System Configuration

VN-MATRIX User Guide

Page 56

I458GB issue 6

Troubleshooting


If you have followed the procedures on the preceding pages, you should by now have at least one
VN-MATRIX encoder and one VN-MATRIX decoder and be able to display the source (encoder) on
the display (decoder). If not, this section will help to diagnose most problems that you may encounter.

Most problems in a VN-MATRIX system will manifest themselves as some kind of disruption of the
target display. Use the Display checkup (see page 57) as a starting point to trace common problems,
either with the decoder/display or elsewhere in the system.
