VN-MATRIX User Guide

Section 2: Installation & Basic Setup Procedures

I458GB issue 6

Page 33

To access the setup menus…

Connect the power to the VN-MATRIX (or, if already connected, cycle the power off then on).


VN-MATRIX will commence sending setup/diagnostic data which should appear in the

HyperTerminal window. After a few seconds this will conclude with something like:

VN Matrix(R) Maintenance Console: ver3.1c

(none) login: ThorPci Init

registering plx interrupt routine = D17F89FC, -780166896

Hello kernel

thor_init_module: pre-ioremap

thor_init_module: post-ioremap

Hello kernel, this is MK registering

registering plx interrupt routine = D296BD30, 0


Press the key: the VN-MATRIX should respond with the following login prompt:

VN Matrix(R) Maintenance Console: ver3.1c

192.168.0.1 login:


NOTE: The login prompt will be preceded by the current IP Address of the unit.


Type config followed by the key.


When prompted for a password type config followed by the key.

The following menu will then appear:


Network Port 1 Network Port 2

============== ==============

1. Boot method: static [dhcp] 11. Boot method: static [dhcp]

2. address: 192.168.0.18 12. address: 192.168.1.18

3. netmask: 255.255.255.0 13. netmask: 255.255.255.0

4. gateway: 192.168.0.1

5. broadcast: 192.168.0.255 15. broadcast: 192.168.1.255

6. mtu: 1500 16. mtu: 1500

7. controller ip: 192.168.0.18

8. controller port: 5432 18. webserver port: 80

9. Exit


Change the settings as required by typing the option number followed by the key. Then

type the new value followed by the key.

For example, to change the Network Port 1 IP address to 172.28.232.16:

type 2 then type 172.28.232.16

NOTE: Do not include any leading zeros when typing IP addresses.
For example, type 192.168.0.18 and not 192.168.000.018.
