Extron Electronics TLP 350MV User Guide User Manual
Page 45
4.
Remove the buttons that are being replaced.
5.
Replace the buttons, as required, making sure that they are in the correct orientation.
Remove Buttons
4
Figure 41.
Remove and Replace the Buttons
6.
Replace the bezel that was removed in step 2. Four clips, two at the top and two at the
bottom, snap into place, audibly.
PC
LA
PT
OP
DV
D
DO
C C
AM
AU
XIL
IAR
Y
DIS
PLA
Y O
N
DIS
PLA
Y O
FF
MU
TE
Clips (4)
Replacement
Buttons
Figure 42.
Replace the Bezel
7.
Reconnect the power to the TLP 350MV.
TLP 350MV • Button Kits
39
