Page 43

Use Factory Firmware

Reset to

Factory Defaults

Run/Stop Events

Reset all IP Settings

The TLP 350 reverts to the factory default
firmware. Event scripting does not start if the
TLP 350 is powered on in this mode. All user files
and settings (drivers, adjustments, IP settings, etc.)
are maintained.

TLP 350MV Reset Mode Summary

Mode Activation

Result

Purpose/Notes

Hold down the recessed Reset
button while applying power to the
TLP 350.

This mode reverts to
the factory default
firmware version if
incompatibility
issues arise with
user-loaded
firmware.

3 Hold down the Reset button for

about 3 seconds until the Power LED
blinks once, then release and press
the Reset button (for less than1
second) within 1 second.

4 Hold down the Reset button for

about 6 seconds until the Power LED
blinks twice (once at 3 seconds, again
at 6 seconds). Then release and press
the Reset button (for less than1
second) within 1 second.

This mode turns events on or off.

This Mode:
• Enables ARP capability.
• Sets the IP address back to the factory default

(192.168.254.254).

• Sets the subnet back to the factory default.
• Sets the default gateway address to the factory

default.

• Sets port mapping back to the factory default.
• Turns DHCP off.
• Turns events off.

This mode is useful
for troubleshooting.

5 Hold down the Reset button for

about 9 seconds until the Power LED
blinks three times (once at 3 seconds,
again at 6 seconds, and again at
9 seconds). Then release and press
the Reset button (for less than1
second) within 1 second.

This Mode performs a complete reset to
factory defaults (except the firmware).
• Does everything mode 4 does.
• Removes button/touchpanel configurations.
• Resets all IP options.
• Removes scheduling settings.
• Removes/clears all files from the TLP 350.

This mode is useful
if you want to start
over with
configuration and
uploading, and also
to replace events.

This mode enables
you to set IP address
information using
ARP and the MAC
address.

NOTE:

User-defined web
pages may not
work correctly if
using an earlier
firmware version.

NOTE: If you do not want to update firmware, or

you performed a mode 1 reset by mistake, cycle
power to the TLP 350 to return to the firmware
version that was running prior to the mode 1
reset. Use the 0Q SIS command to confirm that
the factory default firmware is no longer
running (look for asterisks following the version
number.)

NOTE: After a mode 1 reset is

performed, update the TLP 350
firmware to the latest version. Do
not operate the firmware version
that results from this mode reset.
If you want to use the factory
default firmware, you must upload
that version again. See page 15
for details on uploading firmware.

NOTE: Nothing happens if the momentary press

does not occur within 1 second.

NOTE: Nothing happens if the

momentary press does not occur
within 1 second.

NOTE: Nothing happens if the

momentary press does not occur
within 1 second.

TLP 350MV • Reset Modes
