This section provides information about the on-screen menus that are used in the initial
configuration and calibration of the TLP 350MV. The menus are factory-installed and cannot
be altered by the user.
When power is initially applied to the TouchLink Panel, the unit boots up and displays the
opening screen. To access the on-screen menus, press the Menu button, which located
below the screen, behind the bezel (
g in figure 4 ).
Main Screen
The menus open at the Main Screen. There are five different screens (Main, Volume
(Vol), Time (Time), Network (IP), and Video (Vid). These can be selected by pressing
the appropriate button around the edges of the screen. There is also an Exit button at the
bottom right corner of the screen for leaving the menus.
Main
Vol
Time
IP Exit
Dn Up
Dn
On On
Up
On
Sleep: 00000 Sec
Backlight: 075%
Auto
Vid
LED Motion
Backlight
PoE
Active
Figure 8. Main Setup Screen
The Main screen allows Sleep timer, Backlight, Auto Backlight, and LED Backlight to be
adjusted:
Sleep timer — determines how long the panel is inactive before it enters Sleep mode.
Press the Dn (down) or Up buttons or use the volume control knob to adjust the time from
0 to 50,000 seconds (in 10-second increments). The time that is currently selected is shown
above the buttons.
Sleep mode is overridden when the motion sensor detects movement in front of the screen
or when the screen is touched.
NOTE: When the sleep mode is overridden by a press on the touch screen, the first
press is ignored to avoid inadvertent button operation. Subsequent presses on
buttons engage button functions.
TLP 350MV • Initial Configuration 8
