Time Screen
Month: 08
Day: 03
Year: 2010
Hours: 17
Minutes: 30
Main
Dn Up
Dn Up
Dn Up
Dn Up
Dn Up
Figure 10. Time Screen
Use the Dn (down) and Up buttons or the volume control knob to adjust the Month, Day,
Year, Hours, and Minutes.
NOTE: The Hours value uses the 24 hour clock. For 10 am, set Hours to 10; for 10 pm,
set Hours to 22.
After adjusting the Time screen, return to the Main screen to calibrate the next set of
options.
IP Screen
Main
192.168.254.254
MAC
00-05-A6-05-7D-A6
Off
255.255.000.000
IP Address
DHCP
Subnet Mask
192.168.254.254
MAC
00-05-A6-05-7D-A6
Off
255.255.000.000
IP Address
DHCP
Subnet Mask
CLR
3
6
9
2
5
8
0
1
4
7
.
Main
Figure 11. Network Screen without (left) and with (right) Keypad
Set the IP Address or Subnet Mask by pressing the appropriate address. That address is
highlighted and an on-screen keypad appears that allows the user to type an address.
NOTE: Consult with your IT Department to obtain suitable addresses.
DHCP — toggle the On and Off button to enable or disable Dynamic Host Configuration
Protocol (DHCP).
After adjusting the IP screen, return to the
Main screen to calibrate the next set of
options.
TLP 350MV • Initial Configuration 10
