Feature Description
Motor model Electronically commutated motor
with permanent magnet rotor
Series ecocirc XL
ecocirc XLplus
Rated voltage 1 x 230 V ±10%
Frequency
50/60 Hz
Power con-
sumption
40÷1700 W
IP protection IP 44
Insulation
class
Class 155 (F)
Maximum
working pres-
sure
The maximum pressure is indicat-
ed on pump data plate
0.60 MPa (6 bar)
1.0 MPa (10 bar)
Permitted liq-
uid tempera-
ture
The maximum temperature is indi-
cated on pump data plate
from -10°C (14°F) to +110°C
(230°F) for heating pumps
from -10°C (14°F) to +85°C (185°F)
for domestic hot water pumps
Permitted
ambient tem-
perature
from 0°C (32°F) to 40°C (104°F)
Permitted
ambient hu-
midity
< 95%
Permitted
pumping me-
dia
Heating water according to VDI
2035, water/glycol mixtures 10 up to
50%.
Sound pres-
sure
≤ 43 dB (A)
EMC (electro-
magnetic
compatibility)
EN 55014-1:2006 + A1:2009 +
A2:2011, EN 55014-2:1997 +
A1:2001 + A2:2008, EN
61000-3-2:2006 + A1:2009 +
A2:2009, EN 61000-3-3:2008,
61800-3:2004+A1:2012.
Leakage cur-
rent
< 3.5 mA
I/O auxiliar
+15 VDC
power supply
(Not available
on 25-40,
25-60, 32-40,
32-60 mod-
els)
Imax < 40 mA
Fault signal
relay
Vmax < 250 VAC
Imax < 2 A
3.4 Scope of delivery
Inside the package you will find:
• Pump unit
• Insulating shells (single head only)
• Gasket (OR) to be used as replacement for the
OR mounted between motor and pump hous-
ing
• Plug connector (for 25-40, 25-60, 32-40, 32-60
models only)
• Seal for threaded connection (only for threaded
pump housing)
• Seal for flanged connection (only for flanged
pump housing)
• Eight M12 washers and eight M16 washers (for
models from DN32 to DN65)
• Eight M16 washers (for DN80 and DN100 PN6
model)
• Sixteen M16 washers (for DN80 and DN100
PN10 models)
3.5 Accessories
• Counter flanges
• Blind flanges
• Port to port adapters
• Pressure sensor (for details see section 5.2.9 of
this manual)
• Temperature probe (for details see section
5.2.9 of this manual)
• RS485 module (only for ecocirc XLplus)
• Wireless module (only for ecocirc XLplus)
4 Installation
Precautions
WARNING:
• Observe accident prevention regu-
lations in force.
• Use suitable equipment and protec-
tion.
• Always refer to the local and/or na-
tional regulations, legislation, and
codes in force regarding the selec-
tion of the installation site, plumb-
ing, and power connections.
4.1 Pump handling
WARNING:
Observe local regulations setting the
limits for manual lifting or handling.
Always lift the pump by the pump head or pump
housing. If the pump weight exceeds the manual
handling limits, use lifting equipment, positioning
lifting straps according to Figure 11 .
4.2 Facility requirements
4.2.1 Pump location
DANGER:
Do not use this unit in environments
that may contain flammable/explosive
or chemically aggressive gases or pow-
ders.
10 Performance of the pump is referred to water at 25°C (77°F). Pumped media with different viscosity will have impact
on such performances.
