WARNING !
Every time a change is made, remember to click onto the appropriate
“Apply” button to confirm the change.
Contrary if this “Apply” button has not been clicked, the change has no
effect and when the web page is reloaded the old value appears.
If, after having confirmed the change, a error pop-up appears, means
that the UPS cannot accept this change at all, or perform this change
at this moment.
The Web Interface includes different web pages. The menu frame on the left-hand side of the page
provides links to the various pages. It is a dynamic menu, which is automatically configured depending
on the UPS configuration. The sub-items under a header can be shown/hidden by clicking on the
header. In case of a stand-alone single UPS configuration, the menu will include the following entries:
•
UPS [header]
o
Identification [page link]
o
Details [page link]
o
Alarms [page link]
o
PMAD [page link]
o
Test [page link]
o
Control [page link]
o
Configuration [page link]
• Agent Configuration [page link]
• Trap Configuration [page link]
• Special functions [page link]
In case of a parallel configuration, both the overall (System) values and the single UPS values are
available. However, some controls (‘Test’, ‘Control’ and ‘Configuration’ pages) are not available at a
System level.
In a parallel configuration, the top-right corner of the web page will show whether the displayed values
apply to the System or to single UPSs.
The various pages include the following information:
Identification: Gives some basis information regarding the UPS and the SNMP Interface
Card
Details: Shows all details regarding the UPS (battery voltage, input voltage,…)
Alarms: Shows the alarms (Events) of the UPS
PMAD: Shows advanced diagnostic information
Tests: Give the possibility to make some events in the UPS
Control: Shows or changes the parameters regarding the shutdown
Configuration: Shows or changes the parameters regarding the configuration of the
battery, input, ….
Agent Configuration: Shows or changes the parameters regarding the configuration of the
agent (TCP/IP, submask, …).
Trap Configuration: Shows or changes the parameters regarding the configuration of the
trap (TCP/IP trap, Trap UDP port, enabled/disabled trap, …)
Special Function: Offers the possibility to reboot or upgrade the firmware of the agent
