7 CONFIGURATION OPTIONS
The configuration screens of the telnet method and serial method are identical, while the configuration
screens of the web server is a somewhat different (for more details about the web server please refer to
Chapter 6.2).
1
After having executed the steps in either 6.1 or 6.2 the following screen appears
The settings shown are the settings of the currently active configuration.
Using the Telnet/Serial menu you can enter the necessary values in each field by typing the menu item
number/character and then type the value of the selected parameters
Also partial names which are unique are accepted:
Examples: GE> 1
Choose boot-method (0=dhcp, 1=bootp, 2=configured ip/mask/gw) [2]:
0 [Enter]
GE>
2 Enter the necessary value in each field
3 Press to reboot the agent
4
In case of configuration via a serial connection disconnect the RS232 cable from the
SNMP Interface Card
---<>---<>---[-]---[MAC=XX:XX:XX:XX:XX:XX]---
[IP=0.0.0.0] [mask=255.255.255.0] [gateway=0.0.0.0]
-----------------------------------------------------------------------------
1. boot-method = [dhcp] R. clear reset count [0]
2. ip-address = [0.0.0.0] T. ping
3. subnet mask = [255.255.255.0] U. trap config
4. gateway = [0.0.0.0] V. responsible e-mail
5. trap addresses = [0.0.0.0] [0.0.0.0] [0.0.0.0] [0.0.0.0]
6. trap community = [public] [public] [public] [public]
7. trap UDP port = [162] [162] [162] [162]
8. get-community = [public]
9. set-community = [public]
A. sys-contact = [The contact person for this agent]
B. sys-name = [The administrative name of the agent]
C. sys-location = [The physical location of the agent]
D. upsName = [The administrative name of the connected UPS]
E. upsAttachedDev = [The type of equipment connected to the UPS]
F. snmpport = [161] H. telnet server = [on]
G. httpport = [80] I. http server = [on]
J. telnet/http username = [GE]
K. change telnet/http password L. update firmware M. MAC N. reboot
O. cardaddr = [0] P. upsaddr = [0] Q. logout S. ethernet = [Auto]
GE>
