DEH-41304C EntelliGuard® G Circuit Breaker
13 March 14 Section 2 – Product Specifications
©2012 General Electric All Rights Reserved 9
SECTION 2 – PRODUCT SPECIFICATIONS
WARNING
IMPROPER INSTALLATION, OPERATION AND
MAINTENANCE
Ensure only qualified personnel install, operate, service
and maintain all electrical equipment.
Failure to comply with these instructions could
result in death or serious injury.
Table 2.1. Environmental Conditions
Characteristic Parameter
Temperature:
Operating
Ambient (surrounding circuit breaker)
Storage
-5 ºC to 70 ºC
-20 ºC to -5 ºC
-40 ºC to 70 ºC
Humidity 20% RH to 95% RH
Salt fog per ASTM-B117
Vibration (random and sinusoidal) 1 G max., 50 Hz to 500 Hz in X, Y, Z directions
Fungus resistance per ASTM G21
Voltage and current de-rating at altitude above sea level per ANSI C37.20.1, Tables 2 and 3
Noise level <30 dB
Endurance:
closing coil, Shunt trip
motor operator, under voltage release, accessories
20,000 operations
12,500 operations
Table 2.2. EntelliGuard G Short Circuit and Interrupting Ratings: ANSI/UL1066
Interrupting Rating Tier ANSI/UL1066 Devices, LVPCB Envelope 1 Envelope 2 Envelope 3
Type 240 V 480 V 600 V 1/2S Withstand 400,
800,
1200
400, 800,
1600,
2000
3200 400-3200 3200 4000-5000
S 65,000 65,000 50,000 50,000 X
N 65,000 65,000 65,000 65,000 X X
H 85,000 85,000 65,000 85,000 X
P 100,000 100,000 65,000 65,000 X
E 85,000 85,000 85,000 85,000 X
M 100,000 100,000 85,000 85,000 X X
B 100,000 100,000 100,000 100,000 X X
L 150,000 150,000 100,000 100,000 X X
W 200,000 200,000 100,000 100,000 X X
Table 2.3. EntelliGuard G Short Circuit and Interrupting Ratings: UL489
Interrupting Rating Tier ANSI/UL1066 Devices, LVPCB Envelope 1 Envelope 2 Envelope 3
Type 240 V 480 V 600 V 1/2S Withstand 400-
1200
400-2000 2500-3000 400-3000 3000 4000 5000-
6000
S 65,000 65,000 50,000 42,000 X
N 65,000 65,000 65,000 42,000 X X
H 85,000 85,000 65,000 50,000 X X
P 100,000 100,000 65,000 50,000 X
M 100,000 100,000 85,000 65,000 X X X
L 150,000 150,000 100,000 85,000 X X X
W 200,000 200,000 100,000 85,000 X X X
