EntelliGuard® G Circuit Breaker
DEH-41304C
Section 2 – Product Specifications
13 March 14
10
©2012 General Electric All Rights Reserved
Table 2.4. EntelliGuard G Non-Automatic Circuit Breaker: ANSI Version*
Envelope
Type
Amps
Rated
Interrupting
Current
Rated Endurance
Minimum Mechanical
Endurance
Minimum Electrical
Endurance at 480 V
Minimum Electrical
Endurance at 600 V
1
S
800
42
12,500
10,000
7,500
1
N
800
42
12,500
10,000
7,500
1
N
1600
42
12,500
10,000
7,500
1
N
2000
42
12,500
7,500
5,000
2
M
3200
65
5,000
5,000
5,000
3
B
4000
100
5,000
3,000
2,000
3
B
5000
100
5,000
2,000
1,500
Table 2.5. EntelliGuard G Non-Automatic Circuit Breaker/Molded Case Switch: UL Version*
Envelope
Type
Amps
Short
Interrupting
Current (kA)
Rated Endurance
Minimum Mechanical
Endurance
Minimum Electrical
Endurance at 480 V
Minimum Electrical
Endurance at 600 V
1
S
800
42
12,500
10,000
7,500
1
S
1200
42
12,500
10,000
7,500
1
N
800
42
12,500
10,000
7,500
1
N
1600
42
12,500
10,000
7,500
1
N
2000
42
12,500
7,500
5,000
2
M
3000
65
5,000
5,000
5,000
3
B
4000
100
5,000
3,000
2,000
3
B
5000
100
5,000
3,000
1,500
3
B
6000
100
5,000
1,500
1,000
* GE internal quality testing requirements exceeded 20,000 mechanical and electrical operations.
Table 2.6. Key to Tables 2.2 through 2.5
Type Description
Type Description
E
Sq. Rated (ICW = ICU) 400 A to 2000 A, 85 kAIC at 480/508 V
H 85 kAIC at 480/508 V; 65 kAIC at 600/635 V
B Sq. Rated (ICW = ICU) 3200 A to 6000 A, 100 kAIC at 480/508 V
M 100 kAIC at 480/508 V; 85 kAIC at 600/635 V
N 65 kAIC at 480/508/600/635 V
L
150 kAIC at 480/508 V; 100 kAIC at 600/635 V
W 200 kAIC at 480/508 V; 100 kAIC at 600/635 V
Table 2.7. Agency Certification (All industry standards referenced in this table are the latest version at the time the
product is sold.)
Standard Number
Title
ANSI C37.13,16,17, 20, 50
Low-voltage AC Power Circuit Breakers
NEMA SG 3, 5
Low-voltage Power Circuit Breakers
NEMA AB1
UL 1008*
Automatic Transfer Switches
UL 1066
Low voltage AC and DC Power Circuit Breakers Used in Enclosures
UL 489
Molded-Case Circuit Breakers, Molded-Case Switches and Circuit-Breaker Enclosures
CSA 22.2, No 5.1
Molded-Case Circuit Breakers, Molded-Case Switches and Circuit-Breaker Enclosures
IEC 60947 Part 1
Low Voltage Switchgear and Control Gear - General Rules
IEC 60947 Part 2
Low Voltage Switchgear and Control Gear - Circuit-Breakers
IEC 60947 Part 5
Low Voltage Switchgear and Control Gear - Accessories
IEC 60947 Part 3
Low Voltage Switchgear and Control Gear - Switches, Disconnects, Switch-Disconnects and
Fuse-Combination Units
IEC Environmental: 68-2-1,-2,-3,-6,-11,-
14,-14,-27,-29,-30,-31
IEC Environmental: 721
GB14048
China standards and CCC Mark
ABS (American Bureau of Shipping
Germanischer Lloyds
CUL
Low-voltage AC Power Circuit Breakers
*Suitable for use in UL1008 applications.
