42 XII 2009
EASY DMX SO Operation
Two white channels configuration
Independent light
point no.
DMX starting
address
Used DMX channel
Warm white = red Cold white = blue
1 1 1 2
2 3 3 4
3 5 5 6
… … … …
16 * 31 31 32
… … … …
32 ** 63 63 64
… … … …
64 *** 127 127 128
* Maximum in case of EASY DMX 16x4 SO
** Maximum in case of EASY DMX 32x4 SO
*** Maximum in case of EASY DMX 64x4 SO
5,6
1,2
1,2 1,2
3,4
EASY DMX
7,8
7,8
O n 1
2
O n 1
2
L N
EASY signal
t a (°C )
0...+ 50
2 1 3 4
DMX out
+ - Shield
Sync
Cmd
1 - ON 120Ω Termin.
1 - ON Test Mode
2 - ON Slave / OFF Master
Temp.-Test
t C = 60°C 110
Made in Italy by OSRAM
A6022790072
2 - N.C.
wire preparation push in
s+f: 0.5 – 2.5
10 - 12 mm
EASY DMX 16x4 SO 2
110-240 V _ ~
60-40mA
0/50/60Hz
EASY
signal
DMX addresses
DMX cable
First light point
Second light point
Fourth light point
DMX addresses
DMX addresses DMX addresses
DMX addresses
Third light point
DMX addresses
DMX addresses
