Easy dmx – OSRAM EASY DMX 16x4 SO User Manual
Page 40
40
XII 2009
EASY DMX SO
Operation
Other configurations
RGBW configuration
Independent light
point no.
DMX starting
address
Used DMX channel
R
G
B
W
1
1
1
2
3
4
2
5
5
6
7
8
3
9
9
10
11
12
…
…
…
…
…
…
16 *
61
61
62
63
64
…
…
…
…
…
…
32 **
125
125
126
127
128
…
…
…
…
…
…
64 ***
253
253
254
255
256
* Maximum in case of EASY DMX 16x4 SO
** Maximum in case of EASY DMX 32x4 SO
*** Maximum in case of EASY DMX 64x4 SO
“Single light point” applications
The RGBW configuration fits to “single light point” applications where RGBW fixtures
as well as RGB fixtures are used.
All RGBW fixtures use the DMX channels 1, 2, 3 and 4.
EASY DMX
1,2,3,4
1,2,3,4
1,2,3,4
EASY DMX
1,2,3
1,2,3
1,2,3
O
n
1
2
O
n
1
2
L
N
EASY signal
ta (°C )
0...+50
2
1
3
4
DMX out
+
-
Shield
Sync
Cmd
1 - ON 120Ω Termin.
1 - ON Test Mode
2 - ON Slave / OFF Master
Temp.-Test
t
C
= 60°C
110
Made in Italy by OSRAM
A6022790072
2 - N.C.
wire preparation
push in
s+f: 0.5 – 2.5
10 - 12 mm
EASY DMX 16x4 SO
2
110-240V
_
~
60-40mA
0/50/60Hz
EASY
signal
O
n
1
2
O
n
1
2
L
N
EASY signal
ta (°C )
0...+50
2
1
3
4
DMX out
+
-
Shield
Sync
Cmd
1 - ON 120Ω Termin.
1 - ON Test Mode
2 - ON Slave / OFF Master
Temp.-Test
t
C
= 60°C
110
Made in Italy by OSRAM
A6022790072
2 - N.C.
wire preparation
push in
s+f: 0.5 – 2.5
10 - 12 mm
EASY DMX 16x4 SO
2
110-240V
_
~
60-40mA
0/50/60Hz
EASY
signal
DMX addresses
DMX addresses
DMX addresses
DMX cable
DMX addresses
DMX addresses
DMX addresses
DMX cable
