Document Number: ZXTxRM-5110m
Page
68
FT
0x24 (36d)
Flow Control
Threshold
0 ‐ (DI buffer size ‐ 0x11)
[Bytes]
Serial
Interfacing
2
DI buffer size
minus 0x11
GD
0x10 (16d)
Receive Good Count
0 ‐ 0xFFFF
Diagnostics
2
0
HP
0x11 (17d)
Hopping Channel
0 ‐ 9
Networking &
Security
1
0
HT
0x03 (3d)
Time before Wake‐up
Initializer
0 ‐ 0xFFFF [x 100 msec]
Sleep (Low
Power)
2
0xFFFF
(65535d)
HV
‐
Hardware Version
0 ‐ 0xFFFF [read‐only]
Diagnostics
2
‐
ID
0x27 (39d)
Modem VID
0x11 ‐ 0x7FFF (user‐
settable)
0x8000 ‐ 0xFFFF (factory‐
set, read‐only)
Networking &
Security
2
0x3332
(13106d)
KY
0x3C (60d)
AES Encryption Key
0 ‐ (64 hex digits all set to
'F')
Networking &
Security
2
0 (disabled)
LH
0x0C (12d)
Wake‐up Initializer
Timer
0 ‐ 0xFF [x 100 msec]
Sleep (Low
Power)
1
1
MD
v2.x20*
0x31 (49d)
RF Mode
0 ‐ 6
Networking &
Security
1
0
MK
0x12 (18d)
Address Mask
0 ‐ 0xFFFF
Networking &
Security
2
0xFFFF
(65535d)
MT
0x3D (61d)
Multi‐Transmit
0 ‐ 0xFF
Networking &
Security
1
0
MY
0x2A (42d)
Source Address
0 ‐ 0xFFFF
Networking &
Security
2
0xFFFF
(65535d)
NB
0x23 (35d)
Parity
0 ‐ 4
Serial
Interfacing
1
0
PB
v2.x20*
0x45 (69d)
Polling Begin Address
0 ‐ 0xFFFF
Networking &
Security
2
0
PD
v2.x20*
0x47 (71d)
Minimum Polling
Delay
0 ‐ 0xFFFF
(Base: (x 1 ms), Remote:
[x 10 ms])
Networking &
Security
2
0
PE
v2.x20*
0x46 (70d)
Polling End Address
0 ‐ 0xFFFF
Networking &
Security
2
0
PK
0x29 (41d)
Maximum RF Packet
Size
1 ‐ 0x800 [Bytes]
RF Interfacing
2
varies
PL
0x3A (58d)
TX Power Level
0 ‐ 4
RF Interfacing
1
4 (1 Watt)
PW
0x1D (29d)
Pin Wake‐up
0 ‐ 1
Sleep (Low
Power)
1
0
RB
0x20 (32d)
Packetization
Threshold
1 ‐ Current value of PK
Serial
Interfacing
2
0x800 (2048d)
RC
‐
Ambient Power ‐
Single Channel
0 ‐ 0x31 [dBm, read‐only] Diagnostics
1
‐
RE
0x0E (14d)
Restore Defaults
‐
(Special)
‐
‐
RM
‐
Ambient Power ‐ All
Channels
No parameter ‐ 0x7D0
Diagnostics
2
‐
RN
0x19 (25d)
Delay Slots
0 ‐ 0xFF [slots]
Networking &
1
0
