Document Number: ZXTxRM-5110m
Page
36
Stop bits sent at the end of every character allow the receiving signal hardware to detect
the end of a character and to resynchronize with the character stream. Electronic devices
usually use one stop bit. If slow devices are used, one-and-one half or two stop bits are
required.
Connect Button : The Connect Button will connect to a radio modem using the
configuration selected using the pull down menu items.
Figure 5-17 Connect Button
When you press the Connect Button, the manager software will attempt to connect to the
radio modem using the settings selected with the pull down options. The Radio Modem
Search Screen will be displayed. If the settings are correct and a Radio Modem is found,
click the “OK” button, the Radio Modem Settings Screen will be displayed.
Figure 5-18 Radio Modem Search Screen
