The properties in the dialog box are:
„ ID
The definition number of the PLC register corresponding to the display component.
„ Register num
It is the amount of the registers being displayed or set. The minimum number is 1, and
the maximum is 2.
„ Encrypt
If selected, the data can be changed only when the correct system password is entered.
The command for setting the password is in the menu “Tools(T)”.
„ Show
Input Digit
The maximum number of digits of the data being displayed or set
Point Digit
The length of the significant digits behind the decimal point
„ Indent Manner
Right Indent. When users only want to show the high bit, right Indent can be chosen.
Left Indent. When users only want to show the high bit, left Indent can be chosen.
Example: The presettable value of T register of SG2 is from 0 to 99999. Users can
choose 4 bits to show, left indent, ignore high bits. Now, the value is from 0 to 9999.
„ Decimalist.
The data in the register will be displayed in decimal form.
„ Signed
Only valid when the “Dec.” mode is selected. If the highest digit of the register is 1, the
data will be displayed as a negative number. For example, the hexadecimal number FFFEH
represents –2.
„ HEX/BCD
The data is displayed in hexadecimal form.
„ Set
The component can be used for setting data if it is selected. So the component can be
used for both monitoring and setting the data. The register set box has some special
properties: maximum, minimum and password.
„ Project data
Project data shows proportional data
Example 1:
Set A output as below:
Group name= D; Element name= D0; Register Num= 1; Input Digit= 5; Point Digit= 0;
Decimalist; not show the negative.
