58

AT76C551

1612D–08/01

0 = Disable interrupt

FADDR: Function Address Register

addr 50003C8h

R

8 bits

• Bit 7 – FEN: Function Enable

• Bits 6..0 – FADD[6:0]: Function Address

Note:

Default: 00h

The FIU address register contains the function address assigned by the Host. This Function
Address Register must be programmed by the processor once it has:

1.

Received a SET_ADDRESS command from the Host.

2.

Completed the status phase of the transaction. After power up or reset this register will
contain the value of 0x00.

The Function Enable bit (FEN) allows the firmware to enable or disable the function Endpoints.
The firmware will set this bit after receipt of a reset through the USB hardware. Once this bit is
set the USB hardware passes packets to and from the Host.

ENDPPGPG: Endpoint Ping-pong Enable Register

addr 50003C4h

R

8 bits

Bit 7 – Reserved

• Bit 6 – PG_EP6_EN:Enable Endpoint 6 Ping-pong

• Bit 5 – PG_EP5_EN: Enable Endpoint 5 Ping-pong

• Bit 4 – PG_EP4_EN: Enable Endpoint 4 Ping-pong

• Bit 3 – PG_EP3_EN: Enable Endpoint 3 Ping-pong

• Bit 2 – PG_EP2_EN: Enable Endpoint 2 Ping-pong

• Bit 1 – PG_EP1_EN: Enable Endpoint 1 Ping-pong

• Bit 0 – PG_EP0_EN: Enable Endpoint 0 Ping-pong

Endpoint Control Registers

addr: see below

8 bits

Endpoint Control Registers

addr: see below 8 bits

• Bit 7 R – EPEDS: Endpoint Enable/Disable

0 = Disable Endpoint

1 = Enable Endpoint

• Bit 6 – Reserved

• Bits 5..4 – Reserved and set to 0

• Bit 3 W – DTGLE: Data Toggle

Identifies DATA0 or DATA1 packets.

• Bit 2 R – EPDIR: Endpoint Direction

Only applicable for non-control Endpoints (0 = Out, 1 = In).

• Bits 1..0 R – EPTYPE: Endpoint Type

These bits represent the type of the Endpoint (see Tables 6, 7, 8 and 9).
