45
AT76C551
1612D–08/01
Kc0
addr: 600080 hex W 32 bits
• Bits 31..0 – Kc0[31:0]
Key used for encryption
Note: Default Value: 00000000 hex
Kc1
addr: 600084 hex W 32 bits
• Bits 31..0 – Kc1[31:0]
Key used for encryption
Note: Default Value: 00000000 hex
Kc2
addr: 600088 hex W 32 bits
• Bits 31..0 – Kc2[31:0]
Key used for encryption
Note: Default Value: 00000000 hex
Kc3
addr: 60008C hex W 32 bits
• Bits 31..0 – Kc3[31:0]
Key used for encryption
Note: Default Value: 00000000 hex
ArReg0
addr: 600090 hex RW 32 bits
• Bits 31..0 – ArReg0[31:0]
Used in E_functions.Initialized by firmware and is set by hardware with E_function result.
Note: Default Value: 00000000 hex
ArReg1
addr: 600094 hex RW 32 bits
• Bits 31..0 – ArReg1[31:0]
Used in E_functions. Initialized by firmware and is set by hardware with E_function result.
Note: Default Value: 00000000 hex
