Baseband Interface Pins
TC_CLK O Clock output for transceiver control bus
TC_DATA O Data output for transceiver control bus
TC_ENBL O Enable output for transceiver control bus
TC_LD I Lock detect input
TC_PU_REG O Transceiver voltage regulator power up
TC_PU_PLL O Power up output for transceiver PLL
TC_PU_VCO O VCO power up output
TC_PU_RXTX O Power up output for Transmit/Receive sections of transceiver
TC_RX_ON O RX section power up control output
TC_TX_ON O TX section power up control output
TC_I_CP_SW O Transceiver Current Pump external switch signal
RSSI I Receive signal strength indicator input from transceiver
TXPIN O Transmit data output to transceiver
RXPIN I Receive data input from transceiver
CLK_RXPIN I Clock driven to internal RxFront module
RX_MODE I If “0”, internal clock recovery enabled and data extracted from external A/D. If “1” only BT
packet processing carried out. Clock generation and recovery must be carried out
externally
RXF_PD O Power Down signal for external A/D
RXF_CLK O Clock driven to external A/D
RXF_OE_ O Output enable signal for external A/D
RXF_D[7:0] I A/D RXF_D[7:0] output bus
PCMCIA Interface Pins
PC_A[14:0] I Address Bus – Signals A0 through A14 are address-bus input lines. Signal A0 is always
used since the data interface is 8 bits wide.
PC_D[7:0] B Data Bus – Signals D7 through D0 are the bi-directional data bus for PCMCIA. The most
significant bit is D7.
NWE I Write Enable – Used to strobe memory write data into the chip from the PCMCIA data bus.
Should be deasserted during memory read cycles. It is used for both Common memory
and Attribute memory accesses.
NOE I Output Enable – Active low output enable signal. It is used to gate memory read data from
the BT device onto PCMCIA data bus. It is used for Common memory accesses and
Attribute memory Accesses.
NCE1 I Card Enable – Used to enable even-numbered word address bytes. A0 is used to select
between the even and odd number bytes within the addressed word
