32
AT76C551
1612D–08/01
Hop Frequency Selection
HopSelCtrlStatus 600070 Hop selection control/status register
HopSelKern_ABCDE 600074 Hop selection kernel inputs A, B, C, D, E
HopSelKern_FXY1Y2 600078 Hop selection kernel inputs F, X, Y1, Y2
Rx Front
RxFrontReg 60007C Rx Front register
Packet Encryption
Kc0 600080 Hold the encryption key used for data payload
Kc1 600084 Enciphering/deciphering
Kc2 600088
Kc3 60008C
E_functions
ArReg0 600090 Sets configuration
ArReg1 600094
ArReg2 600098
ArReg3 60009C
KeyReg0 6000A0 Set the half keys used in SAFER Ar rounds
KeyReg1 6000A4
KeyReg2 6000A8
KeyReg3 6000AC
KeyReg4 6000B0
Table 3. Bluetooth Register Set (Continued)
Register Addr. (hex) Function
