31
AT76C551
1612D–08/01
Bluetooth Baseband Register Set
Bluetooth Baseband processor register file is mapped to the AMBA address space. Table 3 summarizes Bluetooth Base-
band registers, grouped in functional sections.
Table 3. Bluetooth Register Set
Register Addr. (hex) Function
Packet Processing
Address0 600000 Sets ADDR field used is various processes
Address1 600004 Access code, packet encoding, encryption, etc.
Pgrsp_counter 600008 Counter used in page response substate
Parity0 60000C Set/Get the parity bits included in current access
Parity1 600010 Code/FHS packet
RSSI_CtrlStatus 600014 Control/Status of RSSI ADC
Controlstatus1 600018 Packet processing control/status 1 register
Controlstatus2 60001C Packet processing control/status 2 register
Bluetooth Clock
CLKN 600020 Native clock (free-running, RO)
CLOCK 600024 Provides estimated clock to frequency hopping
CLKPhase 600028 Native clock phase (free-running, RO)
CLKPhaseCorrelCorrect 60002C Clock phase correction used at correlator trigger
CLKPhaseLimit 600030 Native clock phase limit (sets slot duration)
CLKPhaseWhenCorrel 600034 Native clock phase latched at correlator trigger
CLKControl 600038 Clock control register
CmpTimer_RxTxDataStart 60003C RX/TX start compare timer
CmpTimer_GenPurpose 600040 General purpose compare timer
Transceiver Control
RxTxSettleTimes 600044 Settle times for RX/TX power-up signals
TcCtrlStatus 600048 Transceiver control/status register
TcCommand 60004C Transceiver command register
TcProgData 600050 Transceiver programming (via 3-wire bus) register
Bluetooth Interrupt
IntMask 600054 Bluetooth interrupt mask register
IntStatus 600058 Bluetooth interrupt status register
IntClear 60005C Bluetooth interrupt clear register
Payload FIFOs
RxFifoCtrlStatus 600060 RX FIFO control/status register
RxFifoReadPort 600064 RX FIFO read port (8-bit)
TxFifoCtrlStatus 600068 TX FIFO control/status register
TxFifoWritePort 60006C TX FIFO write port (8-bit)
