H84xx
INSTALLATION GUIDE
H8436-FDS
H8437-EDS
H8400
REG.
R/W NV
Format
Units
Scale
Factor/
Mult.
Range
Description
THD
• 349/350
R
Float
%
0.0-1000.0
THD, Voltage A-N
• 351/352
R
Float
%
0.0-1000.0
THD, Voltage B-N
• 353/354
R
Float
%
0.0-1000.0
THD, Voltage C-N
• 355/356
R
Float
%
0.0-1000.0
THD, Voltage A-B
• 357/358
R
Float
%
0.0-1000.0
THD, Voltage B-C
• 359/360
R
Float
%
0.0-1000.0
THD, Voltage A-C
• 361/362
R
Float
%
0.0-1000.0
THD, Current, Phase A
• 363/364
R
Float
%
0.0-1000.0
THD, Current, Phase B
• 365/366
R
Float
%
0.0-1000.0
THD, Current, Phase C
Modbus Configuration (Downloadable firmware support only)
•
• 7000
R
NV UInt
0-32767
Firmware Version, Reset System (Boot Down Loader)
•
• 7001
R
NV UInt
Firmware Version, Operating System (Application)
•
• 7002/03
R
NV ULong
Serial Number (date/time of manufacture in UTC)
•
• 7004
R
NV UInt
15166
Device ID
•
• 7005
R
NV UInt
1-247
Modbus Address
•
• 7006
R
NV UInt
2400,4800,
9600,19200
Baud rate
•
• 7007
R
NV UInt
Password (always returns 0). Used only for download.
•
• 7008
R
UInt
Self test (always returns 0)
•
• 7009
R
UInt
0,65535
PLOS. Returns the one’s complement of software’s safe vectors flag. Indicates if the
Application (OS) or Boot (Downloader/Reset System) is running.
•
• 7010
R
UInt
Reserved, always returns 0
•
• 7011
R
UInt
Reserved, always returns 0
•
• 7012
R
UInt
Reserved, always returns 0
•
• 7013
R
UInt
Reserved, always returns 0
•
• 7014
R
UInt
Reserved, always returns 0
Command Interface (Downloadable firmware support only)
•
• 7015
R/W
UInt
Command
•
• 7016-031
R/W
UInt
Parameters
•
• 7032
R/W
UInt
Status
•
• 7033
R/W
UInt
Result
•
• 7034
R/W
UInt
I/O Data
•
• 7035-162
R/W
UInt
Data Area
Note 1: Calculate demand using sliding, fixed, or rolling block intervals. See registers 4117-4119 for settings.
Note 2: DOWNLOADABLE FIRMWARE. When the Operating System is erased, only registers 7000-7162 are available. Register 7001 (Firmware Version, Operating System) reads
as 0 in this condition. Additionally, the ID string returned from a “Report ID” query (0x11) will be “Veris Power Meter - RESET SYSTEM RUNNING”.
Note 3: THD (Total Harmonic Distortion) is calculated as the % ratio over the fundamental frequency. H
n
is the nth harmonic.
√ H
2
2
+ H
3
2
+ H
4
2
+ H
5
2
+ ... to the 15th harmonic
H
1
Note 4: Unused or unsupported Integers return 0x8000, Floats 0x7FC00000
