H84xx INSTALLATION GUIDE
H8436-FDS H8437-EDS
H8400
REG.
R/W NV Format Units
Scale
Factor/
Mult.
Range Description
Demand
• 039 R UInt kW W 0-32767 Total Real Power Present Demand
• 040 R UInt kVA W 0-32767 Total Apparent Power Present Demand
• 041 R UInt kVAR W 0-32767 Total Reactive Power Present Demand
• 042 R NV UInt kW W 0-32767 Total Real Power Max Demand
• 043 R NV UInt kVA W 0-32767 Total Apparent Power Max Demand
• 044 R NV UInt kVAR W 0-32767 Total Reactive Power Max Demand
Usage Time
• 045 R NV UInt Hours 1 0-32767 Usage Hours This combination timer counts the total time for
which the absolute current on at least one phase
is >0.1 Amp. • 046 R NV UInt Minutes 1 0-59 Usage Minutes
• 047 R NV UInt Hours 1 0-32767 Total Hours This timer counts the total time since the usage
timer was reset. • 048 R NV UInt Minutes 1 0-59 Total Minutes
• 049 R NV UInt % .01 0-10000 Percent Usage Percent Usage = Usage Time / Total Time .
THD
• 050 R UInt % 0.1 0-10000 THD, Voltage A-N
• 051 R UInt % 0.1 0-10000 THD, Voltage B-N
• 052 R UInt % 0.1 0-10000 THD, Voltage C-N
• 053 R UInt % 0.1 0-10000 THD, Voltage A-B
• 054 R UInt % 0.1 0-10000 THD, Voltage B-C
• 055 R UInt % 0.1 0-10000 THD, Voltage A-C
• 056 R UInt % 0.1 0-10000 THD, Current Phase A
• 057 R UInt % 0.1 0-10000 THD, Current, Phase B
• 058 R UInt % 0.1 0-10000 THD, Current, Phase C
Configuration
--- BDS ---
--- FDS ---
• • 129 R/W UInt N/A
Reset:
- Write 30078 to clear all Energy Accumulators to 0 (All).
- Write 14255 to reset all Power Min/Max to Present Values
(H8400 EDS Only).
- Write 21212 to reset Peak Demand values to Present Demand Values
(H8400 EDS Only).
- Write 10001 to clear the Usage Timers to 0 (H8400 EDS Only).
- Read always returns 0.
• • 130 R/W UInt
10,11,12,30,31,
32,40,42,44
System Type
• • 131 R/W UInt 1-32767 CT Ratio – Primary
Current Inputs
5A 5A 132 R/W UInt 1 or 5 A CT Ratio – Secondary (H8400A Only, unused on H8400V)
• • 133 R/W UInt 1-32767 PT Ratio – Primary
Voltage Inputs • • 134 R/W UInt 0,1,10,100 PT Ratio – Scale (0 = No PT)
• • 135 R/W UInt 100,110,115, 120 PT Ratio – Secondary
• • 136 R/W UInt Hz 50 or 60
• • 137 R/W UInt 0.1
