H84xx INSTALLATION GUIDE
H8436-FDS H8437-EDS
H8400
REG.
R/W NV Format Units
Scale
Factor/
Mult.
Range Description
• • 138 R/W SInt
-4 0.0001
-3 0.001
-2 0.01
-1 0.1
0 1.0
1 10.0
2 100.0
3 1000.0
4 10000.0
Scale Factor I (current) Default = -2
Note: These registers
contain a signed
integer, which
scales the
corresponding
parameters.
• • 139 R/W SInt Scale Factor V (voltage) Default = -1
• • 140 R/W SInt Scale Factor W (power) Default = -2
• • 141 R/W SInt Scale Factor E (energy) Default = -2
• • 142 R UInt Reserved, always returns 0
• • 143 R UInt Reserved, always returns 0
• • 144 R UInt Reserved, always returns 0
• • 145 R UInt Reserved, always returns 0
• • 146 R UInt
Error Bitmap:
bit0: Phase A Voltage out of range
bit1: Phase B Voltage out of range
bit2: Phase C Voltage out of range
bit3: Phase A Current out of range
bit4: Phase B Current out of range
bit5: Phase C Current out of range
bit6: Frequency out of range or insufficient voltage on Phase A to determine frequency.
*range of 45-65 Hz.
bit7: Reserved for future use
bit8: Phase Loss A
bit9: Phase Loss B
bit10: Phase Loss C
bit11-15: Reserved for future use
• • 147 R NV UInt 0-32767 Count of Energy Accumulator resets
--- EDS ---
• 148 R NV UInt 0-32767 Count of Usage Timer resets
• 149 R/W NV UInt Minutes 1-60
(Power) Demand Block Interval – Used for PQS (P=Real Power KW, Q=Reactive Power KVAR,
and S=Apparent Power KVA) demand calculations.
• 150 R/W NV UInt 0-60
Number of Power Demand Block Sub-Intervals - Sets the number of sub-intervals per
Demand Block Interval (above). The method of demand calculation is set as follows:
0 = Sliding Block. Like rolling block, but with a subinterval of 15 seconds is used for Demand
Intervals <= 15 minutes, or 60 seconds for intervals > 15 minutes.
1 = Block. Fixed block with no sub-intervals.
>1 = Rolling Block. The number of sub-intervals per block. This value must divide evenly
into the Block Demand Interval (above). For example, if the Demand Block Interval is 15
minutes, valid Sub-Interval values are: 3, 5, or 15. If the value of 3 is chosen, then there will
be 3 subintervals of 5 minutes each.
Floating Point Statistics
3-Phase Summary
--- BDS ---
• • 257/258 R NV Float kWh Real Energy Consumption
• • 259/260 R Float kW Total Instantaneous Real Power
--- FDS ---
• • 261/262 R Float kVA Total Instantaneous Apparent Power
• • 263/264 R Float kVAR Total Instantaneous Reactive Power
• • 265/266 R Float Ratio 0.0-1.0 Total Power Factor (Total KW / Total KVA)
• • 267/268 R Float Volt Voltage, L-L, Average of 3 Phases
• • 269/270 R Float Volt Voltage, L-N, Average of 3 Phases
• • 271/272 R Float Amp Current, Average of 3 Phases
