H84xx
INSTALLATION GUIDE
H
METER
METER INFO
1;
HELTH
8400U
10
4
25000193
0.5.
R.S.
S.N.
&
MODEL
^
METER
HEALTH STATUS
1;
HELTH
MAINT
OK
&
^
1
RESET
0.010
KWH
RESET ENERGY
No
Yes
The wrench icon is displayed on all
screens when a health problem is
detected (see right). Problems are
shown on the right of the screen with
the location in the center.
Problem:
PLOSS: Phase Loss. F indicates unable to
establish frequency lock on Phase A. In
3 phase systems, A, B, and or C indicates
that the Phase voltage is 25% lower
than the other phases or if the voltage has dropped below 82 volts Line to Neutral.
VCLIP: Voltage Clipping. Indicates the voltage input is too high for the meter to
measure.
ICLIP: Current Clipping. Indicates the current input is too high for the meter to
measure.
-%4%2
(%!,4( 34!453
&!"# 0,/33
!"#
6#,)0
!"#
)#,)0
(%,4(
-!).4
%22/2
>
DIAGNOSTICS
View the Meter Information
1. From the SUMMARY screen, DIAGN (diagnostics)
2. Press METER (meter info).
3. View the meter information (model number, firmware operating system version,
firmware reset system version, and power meter serial number).
Check the Health Status
1. Press HELTH
2. View the health status. If there are no
problems, OK is displayed on the lower
right (see right).
Reset Energy Accumulators: kWh, kVAh, and kVARh, (Ph, Qh, Sh), (H8453V,
H8463V, H8436V)
1. From the SUMMARY screen, RESET is visible.
2. Press RESET.
3. Enter the RESET password (00000 is the default).
4. Press OK.
5. Press YES to RESET, NO to cancel. The RESET value displayed is a lifetime count of
the number of times the energy accumulators have been reset. This is a security
feature to detect tampering.
Reset Menu, (H8437V) (see below)
1. From the SUMMARY screen, RESET is visible.
2. Press RESET.
3. Enter the RESET password (00000 is the default).
4. Press OK.
5. Press -----> until the parameter you want to reset is displayed.
6. Press the parameter to
cancel.
7. Press YES to reset.
8. Menu Options:
METER - Performs all the resets
below.
ENERG - Resets energy
accumulations (the only reset on the H8436V, H8453V and H8463)
DEMND - Resets Demand calculations and maximum values.
MINMX- All stored minimum and maximum values.
TIMER - Resets usage and elapsed timers.
