H84xx INSTALLATION GUIDE
H84XX DEFAULT SETTINGS
Model H8436X/37x H8453x H8463x
CT Primary Ratio 100A 100A 100A
CT Secondary Ratio 1 V 1 V 1 V
PT Ratio 1:1 (none) 1:1 (none) 1:1 (none)
Frequency 60 Hz 60 Hz 60 Hz
Setup Password 00000 00000 00000
Reset Password 00000 00000 00000
Display Mode IEEE IEEE IEEE
System Type 40 40 40
Modbus Address 001 N/A N/A
Modbus Baud Rate 19200 baud N/A N/A
Modbus Parity None N/A N/A
1st Pulse Contact N/A N.O. N.O.
kWh Pulse Width N/A 100ms 100ms
kWh Pulse Energy Index N/A 1 kWh/Pulse 1 kWh/Pulse
2nd Pulse Contact N/A N.O. N.C.
2nd Pulse Contact Output N/A kVARh Phase Loss
kVARh Pulse Width N/A 100ms 100ms
kVARh Pulse Energy Index N/A 1 kVARh/Pulse 1 kVARh
